Abstract

Objectives: The aim of our study was to evaluate the bone to implant contact ratio (BIC) around the implants without primary stability using FDBA, β-TCP and silicate cement.

Material and Methods: In our study, three dogs were selected. The second premolar at each site of the mandible was extracted. In each dog, one site was selected randomly as the control site (G1), and immediate implantation was done with a standard primary stability. In three other sites, an oversized osteotomy was performed, and then the sites were randomized to receive either an implant with zero torque and secured with βTCP and FDBA (G2) or secured with βTCP, FDBA and silicate cement (G3).

Four months after surgery, Individual bone blocks containing of implants were harvested. After dissection, specimens were evaluated using a stereomicroscope (Olympus, Japan). The mean bone to implant contact (BIC) was measured and compared between groups by ANOVA.

Results: Two implants were not successfully osseointegrated. One of them failed in the G2 group and the other was in the G3 group. The mean BICs in the G1, G2, and G3 groups were 30.6%, 60.7%, and 72%, respectively. The results of ANOVA showed that BIC was not significantly different between these three groups (P value = 0.08).

Conclusions: According to our findings, the absence of primary stability when we used graft materials did not increase the failure rate in comparison to the control treatment. Another finding was that the amount of BIC in implants without primary stability was not significantly different from that in stable implants.

Keywords: Alveolar bone grafting, Primary stability, Immediate implantation

INTRODUCTION

There are several factors affecting the long-term success of dental implants [1-3]. Primary stability is a biomechanical stability that is obtained during implant insertion. Different factors, such as bone quality and quantity, geometric design and surgical technique, determine the primary stability. Secondary stability is the biological fixation of dental implants, which is the result of bone repair and is defined as

osseointegration [4,5]. There are controversial results about the effect of low primary stability on the failure of osseointegration [6,7]. Several studies have shown that the micromotion of implants during the healing process could lead to fibrous encapsulation of implants [6,7]. However, the critical level of micromovement that results in failure seems to be dependent on the surface characteristics of implants [8,9]. Rea [10] Evaluated the healing of implants that did not have resistance to rotation. The results of their study showed that even in low torques, osseointegration was achievable, and implant loss before functional loading was not related to the level of insertion torque [10]. According to the results of Ivanoff [11] on rabbits, the osseointegration of implants with initial rotational mobility was similar to that of stable implants. In the majority of implants that are inserted conventionally and do not have resistance to rotation during healing cap placement, contact osteogenesis will lead to successful osseointegration. The achievement of osseointegration of implants without primary stability has been reported. Two different patterns, including contact osteogenesis and distant osteogenesis, have been described for bone formation [12,13]. In contact osteogenesis, bone formation begins on the implant surface, while in distant osteogenesis, bone forms on the parent bone, and osteogenesis continues until it reaches the implant surface. The stability of fresh socket implants is achieved by the insertion of 3 mm of implant in the apical aspect of bone [14]. Studies have shown that distant osteogenesis in graft less fresh socket implants is sufficient for osseointegration [15,16]. To the best of our knowledge, no study has evaluated the success of osseointegration of an implant placed in a socket with zero torque. The present investigation aimed to assess bone healing and BIC around the implants installed with a torque of 0 N·cm and stabilized with a combination of silicate cement and/or BTCP and FDBA in a canine model using stereomicroscopic evaluation.

MATERIAL AND METHODS

All animal procedures followed the standards of the Association for Assessment and Accreditation of Laboratory Animal Care and the Institutional Ethical Animal Care Committee of Mashhad University of Medical Sciences. Three healthy male mongrel dogs aged 4-6 years and weighing 25-35 kg were selected for this study. Dogs were anesthetized with intravenous injection of ketamine hydrochloride 10% (5.5 mg/kg) (Alfasan, Netherlands), sodium thiopental (10 mg/kg) (Nesdonal, Specia, France), and 0.5 mg/kg diazepam (Zepadic Co, Caspian Tamin Pharmaceutical, Tehran, Iran). Then, oroendotracheal intubation was performed. Throughout the surgical procedure, inhaled O2 and intravenous Ringer’s lactate solution (Shahid Ghazi Co, Tehran, Iran) were administered. After the induction of general anesthesia, local anesthesia was applied using the injection of lidocaine 2% with epinephrine 1/80,000 (2 cc) (Daroupakhsh Co, Tehran, Iran) on each mandibular side for hemostasis. After the anesthesia was completed, sulcular incisions were made into the sulcus from the first premolar up to the first molar on both sides of the mandible. A full-thickness flap was reflected and elevated. The second premolar in each quadrant was extracted. Randomization was performed with random codes for the dogs and sockets. Each socket was randomly categorized with the code using a random number table. Then, according to the code in each dog, one site was selected randomly as the control site (G1), and immediate implantation was done with a standard torque and primary stability, such that the apical 3 mm of the implant was inserted into the bone and the stability of the implant during insertion was approximately 25-30 N·cm. without receiving any type of grafting material. A 10-mm-long and 3.7-mm-diameter implant inserted immediately in the fresh socket with the coronal margin nearly flush with buccal alveolar crest on both sides of the mandible (tapered Biohorizon®). After implant placement, a cover screw was attached to the implants manually within the socket using a dedicated screwdriver. In three other sites, an oversized osteotomy was performed.

To achieve an over-prepared site, drilling was continued up to a 4.6 mm drill. The sites were randomized to receive either an implant with zero torque and secured with βTCP: FDBA (1:1) (G2) or an immediate implant placement with zero torque and secured with βTCP, FDBA and silicate cement (G3) (Figure 1A). After placement of the implant into the socket, there was no contact between the fixture and bony wall, and a gap between the implant surface and the bone was detectable all around the fixture. The platform of the implant was placed at the level with their coronal margin almost flush with the buccal alveolar crest on both sides of the mandible (Figure 1A). At one site, the implant was inserted in the same manner, but a combination of FDBA, βTCP and silicate cement in equal proportions was used to fill the gap between the implant and the socket (Figure 1B). In each site, a periapical radiograph from the surgical site was prepared to ensure the correct placement of the implant in accordance with the mentioned protocol. At the end, an incision was made on the periosteum of the flap, and the tension-free flap was sutured by 3-0 Vicryl (Supabone®). During the postoperative period, each dog received an intramuscular injection of cefazolin 1 g every 12 h. They also received diclofenac sodium 75 mg (1 dose every 12 h for 3 days). In the first month after surgery, each animal was kept in a separate room and kept on a soft diet. After surgery, the wound of the surgical site was observed daily to evaluate possible complications. Animals were visited daily for the first week, weekly for the first month and monthly for the remaining follow-up period. Four months after surgery, the animals were anesthetized and euthanized by an overdose of pentobarbital sodium 3% IV (30 mg/kg). Then, 4% formaldehyde solution was perfused through the carotid artery. The jaws were separated, and the soft tissue was detached and kept in formaldehyde solution 10%. A bone block consisting of the implant and surrounding bone was made by a jigsaw, with no injury to the bone surface surrounding the implant, and preserved in buffered 10% formalin solution. The separated pieces were placed in molding material meticulously to be totally covered. After dissection, both sections of the specimens were evaluated using a stereomicroscope (Olympus, Japan) with magnification ranging from 10X to 20X. The photomicrographs showed the proportion of the gap between the implant and bone to the whole surface of the implant (Figure 2). The surface of the implant in contact with the bone and the surface area without bone contact were measured. The ratio of the implant surface area in contact with the bone to the total surface area of the implant was regarded as the percentage of bone-to-implant contact (BIC). The mean BIC was compared between groups by ANOVA.

RESULTS

Two implants were not successfully Osseo integrated. One implant failed in the group having zero torque (G2) and secured with βTCP and FDBA, and the other failed implant was in the group having zero torque and secured with βTCP, FDBA and silicate cement (G3). The mean BICs in G1, G2, and G3 were 30.6%, 60.7%, and 72%, respectively. The results of the Kolmogorov–Smirnov test indicated that the data distribution was normal in all three groups. The ANOVA results showed that BIC was not significantly different between these three groups (P value = 0.08).

DISCUSSION

Several studies evaluated the osteogenesis of implants without primary bone contact. Early studies showed that when the gap between the implant and the bony wall was more than 1 mm, osseointegration may not be achieved [17,18]. According to experimental studies on dogs, [19,20] the coronal portion of bone-to-implant contact was dependent on the size of the gap between the implant and bone. In the Carlsson [21] study, cylindrical titanium implants were inserted into the tibiae of rabbits. All the implants were anchored to the surrounding bone by plates and screws to ensure primary stability. Three holes were prepared in each rabbit. In one hole, the diameter of the implant was similar to the size of the hole, and in two other sites, implants with smaller sizes were inserted. The results of that study showed that after 3 months, the osseointegration around the implants with initial bone contact was significantly more than that of other implants [21]. According to the results of several studies, osteogenic jumping only occurred in defects smaller than 1 mm. However, in the larger defects, bridging the gap took a longer time [17,22,23]. Botticelli [17,24] showed that the healing of defects greater than 2 mm in dogs was similar to that of control sites. In the Sivolella [25] study, there was no significant difference between the osseointegration of implants with a defect width of 0.7 or 1.2 mm and implants with primary bone contact [25]. The difference between the results of the earlier and more recent studies may be related to the different surfaces of implants. Several studies have shown that the surface characteristics of implants are some of the main determinants of osseointegration [12,26,27]. The results of our study were similar to the findings of Sivolella [25]. In their study, the implants were inserted in larger holes to prevent contact between the implant and bony bed, but the implants were completely stabilized by plates. After 3 months, the regions of bone-to-implant contact were visible along the implant surface. In our study, similar to the study by Sivolella [25] there was no primary contact between the implant and bony wall of the socket. Sivolella [25] found, unlike Carlsson [21] that despite the presence of gaps greater than 1 mm, bone formed on the implant surface. This difference could be related to the different implant surfaces. In the Carlsson [21] study, turned implants were used, while the implants used by Sivolella [25] had rough surfaces. Lioubavina-Hack [7] inserted implants with SLA surfaces that did not have initial bone contact in the mandibular ramus of rats. In the control site, the apex of the implant was placed into the bone to achieve appropriate stability, but in the test site, there was no contact between the implant and bone. In the control site, new bone formation in contact with the implant was detectable over time. In the test site, bone-to-implant contact was not seen over the 1-9-month follow-up period. The authors attributed the absence of osseointegration to the micro mobility of implants that caused the formation of a loose fibrous layer between the implant surface and the bone [7]. In that study, the absence of stability in implants without primary bone contact led to the failure of osseointegration. This finding was unlike ours, which showed the successful osseointegration of implants that were inserted with zero torque and did not have any contact with parent bone.

Many researchers have evaluated the effect of primary stability on osseointegration. Some authors believe that the absence of primary stability causes the micromovement of the implant and finally leads to the failure of osseointegration [6,7,28-30]. The results of some other studies showed that with surface roughness, osseointegration is possible even in the presence of micromovement. Animal [31,32] and clinical studies [33,34] have shown the successful healing of implants with low torque (≤10 N·cm). According to the findings of Rea [10] the osseointegration of implants with lower torque was not significantly different from that of implants with higher torque (≥70 N·cm). In this study, even implants with zero torque were successfully Osseo integrated. In an animal study on the tibiae of rabbits, implants with initial rotational mobility had similar osseointegration as stable implants [35]. In another animal study, the immediate displacement of implants inserted in the tibiae of rabbits was 0-90 µm. According to the findings of this study, rough implants with 90 µm displacement had higher BIC, while in implants with turned surfaces, higher BIC values were observed in implants with lower displacement [9]. Different studies have evaluated the effect of low mechanical stability on the survival and success of dental implants. In a cohort study by Cobo-Vázquez [36] the survival of implants without primary stability was evaluated. The findings after one year of follow-up showed that low primary stability did not increase failure. In a retrospective study, the osseointegration of implants without rotational primary stability was evaluated. The findings of this study showed that machined surface implants without rotational primary stability showed a higher survival rate even under immediate loading conditions [34]. Implants that are in contact with parent bone but whose threads have no frictional binding into the bone trabecula clinically do not show resistance to rotation, and they have no detectable apical or lateral movement. According to the results of this retrospective study, such implants were osseointegrated successfully. When using cylindrical implants, a small mismatch between the diameters of the implant and drilling site could lead to the absence of primary stability. Under such conditions, despite the zero torque, contact osteogenesis could improve the osseointegration and decrease the failure rate. The insertion of immediate implants by unexperienced clinicians, the over-preparation of osteotomy sites or unnecessary levels of torque and subsequent fracture of surrounding bone could cause rotational and lateral movement of implants. Under these conditions, distant osteogenesis is the main factor that will lead to successful osseointegration. So far as we know, our study is the first to evaluate the effect of the absence of both bone-to-implant contact and primary stability on the osseointegration process. According to our findings, the absence of these two factors did not increase the failure rate in comparison to the control site. Another finding was that the amount of BIC in implants without primary stability was not significantly different from that in stable implants. Even though the mean BIC in the test group was higher than that in the control group, the difference was not statistically significant. It seems that the use of biomaterials in the gap between the implant and bony wall in the test group could improve osteogenesis. In our study, in two sites of each animal, the combination of βTCP and FDBA was used, and in one site, silicate cement was added to the above combination. The hypothesis behind the use of silicate cement was that increasing the consistency of the biomaterial combination would decrease the micromovement during the healing process and reduce the failure rate. Additionally, several studies have shown the effect of silicate cement on the improvement of osteogenesis because of the increased pH the healing site. In our study, the combination of βTCP, FDBA and silicate cement did not decrease the failure rate and increased the BIC in comparison to the use of only βTCP and FDBA.

REFERENCES

1. White GS (2015) Treatment of the edentulous patient. Oral Maxillofac Surg Clin North Am 27(2): 265-272.
2. Jung RE, Pjetursson BE, Glauser R, Zembic A, Zwahlen M, et al. (2008) A systematic review of the 5‐year survival and complication rates of implant‐supported single crowns. Clin Oral Implants Res 19(2): 119-130.
3. Wittneben J-G, Buser D, Salvi GE, Bürgin W, Hicklin S, et al. (2014) Complication and failure rates with implant‐supported fixed dental prostheses and single crowns: A 10‐year retrospective study. Clin Implant Dent Relat Res 16(3): 356-364.
4. Meredith N (1998) Assessment of implant stability as a prognostic determinant. Int J Prosthodont 11(5): 491-501.
5. Papaspyridakos P, Chen C-J, Singh M, Weber H-P, Gallucci G (2012) Success criteria in implant dentistry: A systematic review. J Dent Res 91(3): 242-248.
6. Brunski JB (1988) The influence of force, motion and related quantities on the response of bone to implant. Non-Cem Total Tip Arthroplasty pp: 7-22.
7. Lioubavina‐Hack N, Lang NP, Karring T (2006) Significance of primary stability for osseointegration of dental implants. Clin Oral Implants Res 17(3): 244-250.
8. Duyck J, Vandamme K, Geris L, Van Oosterwyck H, De Cooman M, et al. (2006) The influence of micro-motion on the tissue differentiation around immediately loaded cylindrical turned titanium implants. Arch Oral Biol 51(1): 1-9.
9. Vandamme K, Naert I, Geris L, Sloten JV, Puers R, et al. (2007) The effect of micro‐motion on the tissue response around immediately loaded roughened titanium implants in the rabbit. Eur J Oral Sci 115(1): 21-29.
10. Rea M, Lang NP, Ricci S, Mintrone F, González GG, et al. (2015) Healing of implants installed in over‐or under‐prepared sites - an experimental study in dogs. Clin Oral Implants Res 26(4): 442-446.
11. Ivanoff CJ, Sennerby L, Lekholm U (1996) Influence of initial implant mobility on the integration of titanium implants. An experimental study in rabbits. Clin Oral Implants Res 7(2): 128-132.
12. Davies JE (1998) Mechanisms of endosseous integration. Int J Prosthodont 11(5): 391-401.
13. Davies JE (2003) Understanding peri-implant endosseous healing. J Dent Educ 67(8): 932-949.
14. Singh A, Gupta A, Yadav A, Chaturvedi T, Bhatnagar A, et al. (2012) Immediate placement of implant in fresh extraction socket with early loading. Contemp Clin Dent 3(Suppl 2): S219-S22.
15. Bersani E, Coppede AR, Prata HHDPP (2010) Immediate loading of implants placed in fresh extraction sockets in the molar area with flapless and graft less procedures: A case series. Int J Periodontics Restorative Dent 30(3): 291-299.
16. Hamouda NI, Mourad SI, El‐Kenawy MH, Maria OM (2015) Immediate implant placement into fresh extraction socket in the mandibular molar sites: A preliminary study of a modified insertion technique. Clin Implant Dent Relat Res 17: e107-e116.
17. Botticelli D, Berglundh T, Buser D, Lindhe J (2003) The jumping distance revisited: An experimental study in the dog. Clin Oral Implants Res 14(1): 35-42.
18. Botticelli D (2006) Healing of marginal defects around implants.
19. Akimoto K, Becker W, Persson R, Baker DA, Rohrer MD, et al. (1999) Evaluation of titanium implants placed into simulated extraction sockets: a study in dogs. Int J Oral Maxillofac Implants 14(3): 351-360.
20. Knox R, Caudill R, Meffert R (1991) Histologic evaluation of dental endosseous implants placed in surgically created extraction defects. Int J Periodontics Restor Dent 11(5): 364-375.
21. Carlsson L, Röstlund T, Albrektsson B, Albrektsson T (1988) Implant fixation improved by close fit Cylindrical implant-bone interface studied in rabbits. Acta Orthop Scand 59(3): 272-275.
22. Buser D, Dahlin C, Schenk R (1994) Guided bone regeneration in implant dentistry. Chicago: Quintessence.
23. Schenk R, Willenegger H (1964) On the histology of primary bone healing. Langenbeck's Arch Surg 308(1): 440-452.
24. Botticelli D, Berglundh T, Lindhe J (2004) Resolution of bone defects of varying dimension and configuration in the marginal portion of the peri‐implant bone: An experimental study in the dog. J Clin Periodontol 31(4): 309-317.
25. Sivolella S, Bressan E, Salata LA, Urrutia ZA, Lang NP, et al. (2012) Osteogenesis at implants without primary bone contact - an experimental study in dogs. Clin Oral Implants Res 23(5): 542-549.
26. Qu J, Chehroudi B, Brunette D (1996) The use of micromachined surfaces to investigate the cell behavioral factors essential to osseointegration. Oral Dis 2(1): 102-115.
27. Wennerberg A, Albrektsson T (2009) Effects of titanium surface topography on bone integration: A systematic review. Clin Oral Implants Res 20: 172-184.
28. Sanz M, Alandez J, Lazaro P, Calvo J, Quirynen M (1991) Histo-pathologic characteristics of peri-implant soft tissues in Brånemark implants with 2 distinct clinical and radiological patterns. Clin Oral Implants Res 2(3): 128-134.
29. Quirynen M, Naert I, van Steenberghe D (1992) Fixture design and overload influence marginal bone loss and future success in the Brånemark system. Clin Oral Implants Res 3(3): 104-111.
30. Isidor F (1996) Loss of osseointegration caused by occlusal load of oral implants. A clinical and radiographic study in monkeys. Clin Oral Implants Res 7(2): 143-152.
31. Pantani F, Botticelli D, Garcia IR, Salata LA, Borges GJ (2010) Influence of lateral pressure to the implant bed on osseointegration: an experimental study in dogs. Clin Oral Implants Res 21(11): 1264-1270.
32. Trisi P, Perfetti G, Baldoni E, Berardi D, Colagiovanni M (2009) Implant micromotion is related to peak insertion torque and bone density. Clin Oral Implants Res 20(5): 467-471.
33. Rodrigo D, Aracil L, Martin C, Sanz M (2010) Diagnosis of implant stability and its impact on implant survival: A prospective case series study. Clin Oral Implants Res 21(3): 255-261.
34. Balshi SF, Wolfinger GJ, Balshi TJ (2007) A retrospective analysis of 44 implants with no rotational primary stability used for fixed prosthesis anchorage. Int J Oral Maxillofac Implants 22(3): 467-471.
35. Hämmerle C, Schmid J, Olah A, Lang N (1996) Influence of initial implant mobility on the integration of titanium implants. An experimental study in rabbits. Clin Oral Implants Res 7(2): 120-127.
36. Cobo-Vázquez C, Reininger D, Molinero-Mourelle P, González-Serrano J, Guisado-Moya B, et al. (2018) Effect of the lack of primary stability in the survival of dental implants. J Clin Exp Dent 10(1): e14.
